Aluminium Bars in Coimbatore, ASME SB221 Aluminium Bars Stockist in Coimbatore, Aluminium Bars Supplier in Coimbatore.
Aluminium bars are long, solid metal products made from high-grade aluminium alloy. They are characterised by their lightweight, excellent corrosion resistance and good strength-to-weight ratio. Jagdish Metal is a leading Aluminium bar supplier and exporter in Coimbatore. Our Aluminium bars are produced to the highest standards such as ASTM B221 and ASTM SB221 specifications, guaranteeing unparalleled quality and dependability. As an ISO 9001:2008 certified company, we guarantee that each product meets strict quality parameters. We deliver all over Coimbatore, including prominent cities like Gandhipuram, Peelamedu, Ukkadam, Singanallur, and R.S. Puram, consistently delivering excellence with every order.
Our Aluminium bars are offered in a wide size range to cater to the diverse needs of our clients. We provide sizes from 5 mm to 500 mm, diameters from 0.1 mm to 100 mm, and lengths from 100 mm to 3000 mm. Our bars are provided with various surface finishes such as Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, and BA Finish. This wide range of options enables customers to select the most appropriate one for their applications.
Aluminium bars are known for their exceptionally high tensile strength, excellent machinability, and superior corrosion resistance. These properties make them ideal for use in construction, transportation, electrical components, and marine industries. Their lightweight nature contributes to cost-effective manufacturing processes, while their durability ensures long-lasting performance. With better surface finishes, our Aluminium bars are also ideal for architectural applications where strength and aesthetics are both critical.
Every Aluminium bar is thoroughly tested, including tensile testing, hardness testing, and corrosion resistance testing, to guarantee that it meets our high-quality standards. We use strong packaging techniques to protect bars during shipping, ensuring they arrive in pristine condition. With years of experience and expertise in the field, we are known for our fast shipping and reliable delivery services across Coimbatore.
Standard Specification : ASTM B221 / ASTM SB221
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 5 To 500 mm
Diameter : 0.1 to 100 mm
Length : 100 To 3000 mm Long & Above
Surface Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Tolerance : H8, H9, H10, H11, H12, H13, K9, K10, K11, K12 or as per clients’ requirements
Form : Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.
| European Standard | BS (OLD) | USA (AA) | Germany (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| EN AW-1070 A | – | 1070 | Al-99.7 | Al-99.7 | 19700 | – |
| EN AW-1100 | IC | 1100 | Al-99.0 | Al-99.0 | 19000 | 2 S |
| EN AW-2011 | FC1 | 2011 | AlCuBiPb | AlCu6BiPb | – | 28S |
| EN AW-2014 | HE15 | 2014 | AlCuSiMn | AlCu4SiMg | 24345 | B26S |
| EN AW-2024 | – | 2024 | AlCuMg2 | AlCu4Mg1 | – | 24 S |
| EN AW-3003 | N3 | 3003 | AlMnCu | AlMn1Cu | 31000 | 3 S |
| EN AW-3103 | – | 3103 | – | AlMn1 | – | – |
| EN AW-6101A | E91E | 6101 | E AlMgSi 0.5 | E AlMgSi(A) | 63401 | D50S |
| EN AW-6005 | – | 6005 | AlMgSi0.7 | AlSiMg | 62400 | C51S |
| EN AW-6351 | HE30 | 6351 | AlMgSi1 | AlSiMg0.5Mn | 64430 | B51S |
| EN AW-6060 | – | 6060 | AlMgSi 0.5 | AlMgSi | – | – |
| EN AW-6061 | HE20 | 6061 | AlMgSiCu | AlMg1SiCu | 65032 | 65S |
| EN AW-6063 | HE9 | 6063 | AlMgSi0.5 | AlMg0.7Si | 63400 | 50S |
| EN AW-6082 | HE30 | 6351 | AlMgSi1 | AlSi1MgMn | 64430 | B51S |
| Alloy | % Si | % Mg | % Mn | % Cu | % Fe | % Cr | % Zn | % Ti | % Others | % Al |
|---|---|---|---|---|---|---|---|---|---|---|
| EN AW-1050 A | 0.25 Max | 0.05 Max | 0.05 Max | 0.05 Max | 0.40 Max | – | 0.07 Max | 0.05 Max | – | 99.5 Min |
| EN AW-1070 A | 0.20 Max | 0.03 Max | 0.03 Max | 0.03 Max | 0.25 Max | – | 0.07 Max | 0.03 Max | – | 99.7 Min |
| EN AW-1100 | Si+Fe 0.95 Max | – | 0.05 Max | 0.05 – 0.20 | – | – | 0.10 Max | 0.05 Max | – | 99.0 Min |
| EN AW-2011 | 0.40 Max | – | – | 5.00 – 6.00 | 0.70 Max | – | 0.30 Max | – | Bi: 0.20 – 0.60, Pb: 0.20 – 0.60 | Remainder |
| EN AW-2014 | 0.50 – 1.20 | 0.20 – 0.80 | 0.40 – 1.20 | 3.90 – 5.00 | 0.70 Max | 0.10 Max | 0.25 Max | 0.15 Max | – | Remainder |
| EN AW-2024 | 0.50 Max | 1.20 – 1.80 | 0.30 – 0.90 | 3.80 – 4.90 | 0.50 Max | 0.10 Max | 0.25 Max | 0.15 Max | 0.15 Max | Remainder |
| EN AW-3003 | 0.60 Max | – | 1.00 – 1.50 | 0.05 – 0.20 | 0.70 Max | – | 0.10 Max | – | 0.15 Max | Remainder |
| EN AW-3103 | 0.50 Max | 0.30 Max | 0.90 – 1.50 | 0.10 Max | 0.70 Max | 0.10 Max | 0.20 Max | 0.10 Max | – | Remainder |
| EN AW-6101A | 0.30 – 0.70 | 0.40 – 0.90 | 0.03 Max | 0.05 Max | 0.40 Max | – | – | – | 0.10 Max | Remainder |
| EN AW-6005 | 0.60 – 0.90 | 0.40 – 0.60 | 0.10 Max | 0.10 Max | 0.35 Max | 0.10 Max | 0.10 Max | 0.10 Max | – | Remainder |
| EN AW-6351 | 0.70 – 1.30 | 0.40 – 0.80 | 0.40 – 0.80 | 0.10 Max | 0.50 Max | – | 0.20 Max | 0.20 Max | 0.15 Max | Remainder |
| EN AW-6060 | 0.30 – 0.60 | 0.35 – 0.60 | 0.10 Max | 0.10 Max | 0.10 – 0.30 | 0.05 Max | 0.15 Max | 0.10 Max | – | Remainder |
| EN AW-6061 | 0.40 – 0.80 | 0.80 – 1.20 | 0.15 Max | 0.15 – 0.40 | 0.70 Max | 0.04 – 0.35 | 0.25 Max | 0.15 Max | – | Remainder |
| EN AW-6063 | 0.20 – 0.60 | 0.45 – 0.90 | 0.10 Max | 0.10 Max | 0.35 Max | 0.10 Max | 0.10 Max | 0.10 Max | – | Remainder |
| EN AW-6082 | 0.70 – 1.30 | 0.60 – 1.20 | 0.40 – 1.00 | 0.10 Max | 0.50 Max | 0.25 Max | 0.20 Max | 0.10 Max | – | Remainder |
| Alloy | Temper | UTS (MPa) Min |
UTS (MPa) Max |
Yield Strength (MPa) Min |
Yield Strength (MPa) Max |
Elongation A50mm (%) Min |
|---|---|---|---|---|---|---|
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
| EN AW-1070 A | F | 60 | – | 20 | – | 23 |
| EN AW-1100 | O | 75 | 110 | – | – | 25 |
| EN AW-2011 | T4 | 275 | – | 125 | – | 12 |
| T6 | 310 | – | 230 | – | 6 | |
| EN AW-2014 | O | – | 250 | – | 135 | 10 |
| T4 | 370 | – | 230 | – | 11 | |
| T6 | 415 | – | 370 | – | 5 | |
| EN AW-2024 | O | – | 250 | – | 150 | 10 |
| T3, T3510, T3511 | 395 | – | 290 | – | 6 | |
| T8, T8510, T8511 | 455 | – | 380 | – | 4 | |
| EN AW-3003 | F | 95 | – | 35 | – | 20 |
| O | 95 | 135 | 35 | – | 20 | |
| EN AW-3103 | F | 95 | – | 35 | – | 20 |
| O | 95 | 135 | 35 | – | 20 | |
| EN AW-6101A | T6 | 200 | – | 170 | – | 8 |
| EN AW-6005 | T4 | 180 | – | 90 | – | 13 |
| T6 | 270 | – | 225 | – | 6 | |
| EN AW-6351 | O | – | 160 | – | 110 | 12 |
| T4 | 205 | – | 110 | – | 12 | |
| T6 | 290 | – | 250 | – | 6 | |
| EN AW-6060 | T4 | 120 | – | 60 | 14 | 12 |
| T5 | 160 | – | 120 | – | 6 | |
| T6 | 190 | – | 150 | – | 6 | |
| T64 | 180 | – | 120 | – | 10 | |
| T66 | 215 | – | 160 | – | 6 | |
| EN AW-6061 | O | – | 150 | – | 110 | 14 |
| T4 | 180 | – | 110 | – | 13 | |
| T6 | 260 | – | 240 | – | 6 | |
| EN AW-6063 | O | – | 130 | – | – | 16 |
| T4 | 130 | – | 65 | – | 12 | |
| T5 | 175 | – | 130 | – | 6 | |
| T6 | 215 | – | 170 | – | 6 | |
| T66 | 245 | – | 200 | – | 6 | |
| EN AW-6082 | O | – | 160 | – | 110 | 12 |
| T4 | 205 | – | 110 | – | 12 | |
| T5 | 270 | – | 230 | – | 6 | |
| T6 | 290 | – | 250 | – | 6 |
